Detect the Signature of Dark Matter With a DIY Antenna

If you happen to’re questioning what dark matter is, you’re not alone. Astronomers don’t know. However they’ve decided that this invisible materials should be much more plentiful than the celebrities and nebulas that they’ll see. They’ve surmised as a lot from observing the gravitational results of all this perplexing darkish stuff, launching a decades-long marketing campaign to grasp its nature.

I just lately realized that it’s doable to sense the presence of darkish matter utilizing a small radio telescope such because the Discovery Dish covered in these pages final yr. The trick is to know what observations to gather and the way to analyze them. I’ll sketch that out beneath, however first let me describe the home made radio telescope I put collectively for this venture.

It’s a pyramidal-horn antenna, not not like the horn antenna first used in 1951 to detect the 1,420.4-megahertz radio emissions from interstellar clouds of impartial hydrogen in house. These emissions maintain the important thing to confirming the presence of darkish matter as a result of such clouds may be discovered all around the galaxy, and their motions replicate what’s taking place in several elements of the Milky Way.

I used an online calculator to assist me design my antenna, adopting dimensions I knew I may obtain utilizing a US $25 10-by-2-foot roll of roof flashing and an emptied one-gallon paint-thinner can. (Subsequent time, I’ll simply purchase an empty F-style can.)

The horn antenna is comprised of tape, an empty paint-thinner can, and a roll of metallic roof flashing [bottom row]. Alerts are picked up with a low-noise amplifier [top middle] and handed to a software-defined radio receiver [top left].James Provost

Building of the antenna itself was much like that of the slightly smaller horn antenna I described in these pages in 2019. I made my new antenna greater, although, as a result of I wanted higher angular decision, permitting me to scan smaller areas of the sky.

To select up the emissions from interstellar hydrogen, I used Nooelec’s $45 SAWBird+ H1, a tool that mixes two low-noise amplifiers with a standing-acoustic-wave filter centered on 1,420 MHz, together with a RTL-SDR V4 dongle. So it’s not too onerous to place collectively the {hardware} wanted to measure alerts from hydrogen clouds. However how do you pull the signature of darkish matter out of these alerts?

The reply is that you just use such measurements to gauge the velocity at which clouds situated at completely different distances from the middle of the Milky Approach are transferring of their orbits.

You simply have to indicate that the velocity at which materials orbits the middle of the galaxy doesn’t fall off with distance.

You may assume that these clouds circle across the galactic middle in the identical method that planets orbit the solar or satellites orbit the Earth, with objects shut in orbiting quicker than these farther out. Mercury, for instance, zips across the solar at 47.4 kilometers per second, whereas Neptune lumbers alongside at a leisurely 5.4 km/s.

The Milky Approach accommodates a central bulge of stars surrounding a supermassive black hole. So at first blush, the mass of the galaxy seems to be concentrated close to its middle. If that have been the case, stars and clouds of different materials would orbit extra slowly as their distance from the middle will increase. If, nevertheless, there have been monumental quantities of invisible matter current all through the galaxy, you wouldn’t count on orbital velocities to decrease on this method.

How Do You Measure the Pace of Interstellar Clouds?

So to detect darkish matter, you simply have to indicate that the velocity at which materials orbits the middle of the galaxy doesn’t fall off with distance. And radio observations are the best method to do this, as a result of you may gauge speeds by measuring how a lot the sign from hydrogen clouds is shifted by the Doppler impact.

By pointing your radio telescope at completely different elements of the sky, you choose up emissions from clouds situated at numerous distances from the galactic middle. The frequency offset of those emissions from 1,420 MHz displays the velocity of method or recession of these clouds relative to Earth.

You want measurements from the aircraft of the galaxy, at galactic longitudes between 0 and 90 levels (a galactic longitude of 0 levels factors immediately towards the middle of the galaxy and 180 levels immediately away from it). Making use of some highschool trigonometry enables you to convert these figures into orbital speeds across the galactic middle, a way often called the tangent-point method.

In any group of clouds, the one with the very best velocity as seen from Earth would be the one mendacity closest to a tangent level alongside its orbit across the galaxy. This permits its distance from the galactic middle to be decided by way of trigonometry [top]. The underside graph reveals the astronomical neighborhood’s measurements for velocities across the galactic middle [in black], with the creator’s outcomes plotted in stuffed and open pink circles.James Provost

Experiments aiming my horn antenna at an Inmarsat geostationary satellite tv for pc revealed that the angular decision of my little radio telescope is about 20 levels. So with the assistance of the planetarium program Stellarium, I pointed my antenna within the aircraft of the galaxy at galactic longitudes of about 15, 30, 45, 60, 75, and 90 levels, spacing issues out in an effort to make every set of measurements largely unbiased.

I used the SDR# software program with a plug-in known as IF Average to learn the uncooked measurements coming in from the antenna. This plug-in stacks up knowledge obtained over a couple of minutes, permitting a weak sign to construct up and produce a clear radio spectrum that reveals the 1,420-MHz line. In actuality, it appears extra like a bump, or perhaps a set of bumps on account of Doppler shifted emissions from a number of clouds, situated at completely different distances from the galactic middle. Happily, you solely must care concerning the cloud that’s receding the quickest—the one with the biggest redshift, in astronomer-speak.

I used Microsoft Excel to research the shapes of radio spectra I gathered, modeling them because the sums of particular person bell-shaped contributions from completely different clouds. That allowed me to estimate the biggest redshift for every galactic longitude I probed. Then, once more utilizing Excel, I utilized formulation that reworked these six redshift values into six pairs of orbital velocities and distances from the galactic middle.

The plot of my outcomes matched moderately properly with a current paper, “The Inner Rotation Curve of the Milky Way,” in Publications of the Astronomical Society of Japan. Two innermost factors did present anomalously low orbital velocities. One other shot at curve becoming in Excel introduced these outcomes nearer to expectations, however they have been nonetheless considerably off.

In any case, the orbital velocities I estimated didn’t diminish with distance from the galactic middle—fairly the alternative. One thing out there’s placing its stamp on how the Milky Approach turns. And that fundamental remark is what permits me to say that, with the assistance of some roof flashing and a paint-thinner can, I’ve been in a position to detect darkish matter from my yard.
